Part number : TT2222 ( = 2SC5793 )

Functions : NPN Transistor ( Vceo : 800V, Vcbo : 1600V, Ic : 10A, Pd : 65W )

Package : TO-220 Type

Manufacturer : Sanyo


Features

1. Transitor for TV
2. High Voltage Color Display Horizontal Deflection Output
3. Color TV Horizontal Deflection Output Applications

TT2222 transistor equivalent

ST2001HI : 1500/800V, 10A, 55W, tf=0,2us [ ST2001HI Datasheet PDF ]

Cattle has two main uses. One of which may be more useful than others. They can provide food for your army; They can often be used in quests from Village Elders, or your Marshal (if you are following them). Browse other questions tagged mount-and-blade mount-and-blade-warband or ask your own question.

KSD5703 : 1500/800V, 10A, 70W, tf=0,1us

TT2202 : 1500/800V, 10A, 30W, tf=0,3us

TT2140 : 1500/800V, 6A, 20W, tf=0,3us [ TT2140 datasheet ]

Pinout

Functions :

1. High speed.
2. High breakdown voltage
3. High reliability (Adoption of HVP process).
4. Adoption of MBIT process.
5. On-chip damper diode.

TT2222 Datasheet PDF

This is one of the semiconductor types.

This part name is TT2222.

Function : TT2222 Transitor for TV, High Voltage Color Display Horizontal
Deflection Output, Color TV Horizontal Deflection Output Applications

Manufacturers of product is Sanyo.

See the preview image and the PDF file for more information.

TT2222 Transistor Datasheet

TT2222 transistor equivalent
